LEGEND SUSPENSION REVO-A Mono Shock - 13" - Standard - M-Eight Softail Models 1310-2249 is backordered and will ship as soon as it is back in stock.
LEGEND SUSPENSION REVO-A Mono Shock - 13" - Standard - M-Eight Softail Models 1310-2249
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
Most items ship for free to the continental United States
LEGEND SUSPENSION REVO-A Mono Shock - 13" - Standard - M-Eight Softail Models 1310-2249
Description
Description
REVO-A Mono Shock - 13" - Standard - M-Eight Softail Models
Revo-A coil designed specifically for M-8 Softail models, Available in 12.5", 13", and 13.5", standard or heavy-duty applications, Adjustable preload for rider set up, also allows for minimal pre-load adjustment when changing between rider's weights and loads, Legend's touring specific spring rates provide superior ride comfort, improved performance, and increased resistance to bottoming for all day comfort , Features adjustable rebound damping that is specifically designed to make fast, precise, and repeatable changes to ride comfort and performance with a simple turn of a knob, Provides optimum rebound performance that can be fine-tuned for any given rider weight, personal ride preference, or personal riding style, Low friction sleeve bearings both top and bottom for ease of installation, this also allows the shock to float in its mount and avoid shock bind, Hard anodized, 46 mm billet aluminum mono tube design utilizes a lightweight high flow piston design for improved fluid flow resulting in unmatched handling and bike control, Hard chromed shaft is 14% larger for increased strength, Internal floating nitrogen piston ensures consistent damping performance, Deflective disc valving self-adjusts to frequency and ensures controlled performance, Legend's durable and low friction sealing system and sliding bearings provide improved performance and feel, Available in Black Type III hard coat anodize, Easy installation that utilizes the OEM mounting hardware, Included preload wrench makes adjusting easy, Sold as Mono Shock (1 shock only), Designed for optimum performance with the Legend Axeo front suspension, Made by hand in Sturgis, SD, USA, P65 WARNING: Cancer and Reproductive Harm
Specifications
- Brand: Legend Suspension
- Product: coilover monotube shock absorber
- Mounting position: rear
- Material: billet aluminum
- Color/finish: black / anodized
- Riding style: Street
- Damping Method: Deflective Disc
- Duty: Standard
- Adjustment Type: Adjustable Rebound Damping
- Model: Revo-A
- Extended Length: 13.00"
- Part number: 1310-2249
- Supplier SKU: 1310-2249
- Units: each
Harley-Davidson Fitment
| Make | Years | Model | Details |
|---|---|---|---|
| Harley-Davidson | 2018–2024 | FLFBS Fat Boy 114 | |
| Harley-Davidson | 2018–2024 | FLHCS Heritage Classic 114 | |
| Harley-Davidson | 2021–2024 | FXBBS Street Bob 114 | |
| Harley-Davidson | 2022–2024 | FXLRS Low Rider S 117 | Softail |
| Harley-Davidson | 2022–2024 | FXLRST Low Rider ST 117 | Softail |
| Harley-Davidson | 2018–2021, 2023 | FXFBS Fat Bob 114 | |
| Harley-Davidson | 2022 | Softail Street Bob FXBB | |
| Harley-Davidson | 2018–2021 | FLHC Heritage Classic 107 | |
| Harley-Davidson | 2018–2021 | FLSB Sport Glide 107 | |
| Harley-Davidson | 2018–2021 | FLSL Softail Slim 107 | |
| Harley-Davidson | 2020–2021 | FXLRS Low Rider S 114 | Softail |
| Harley-Davidson | 2018–2020 | FLDE Deluxe 107 | |
| Harley-Davidson | 2018–2020 | FXBB Street Bob 107 | |
| Harley-Davidson | 2018–2020 | FXBRS Breakout 114 | |
| Harley-Davidson | 2018–2020 | FXLR Low Rider 107 | |
| Harley-Davidson | 2018–2019 | FLFB Fat Boy 107 | |
| Harley-Davidson | 2018–2019 | FXBR Breakout 107 | |
| Harley-Davidson | 2018–2019 | FXFB Fat Bob 107 |
Please confirm fitment for your specific model year.
